UTP Cat5e Cat6 kab/rezo kab/LAN kab
1. Kondiktè: 0.50±0.01mm(24AWG) kwiv Bare
2. izolasyon: 0.90±0.03mm HDPE
3. Nwayo/Pè: 8/4
4. djenn: 5.0±0.3mm PVC (PE, LSZH)
Opsyon: Jele Compound, Jacket: UV, FR, RoHS respekte.
Pwopriyete mekanik:
| Elongasyon | Min. 300% |
| Ranje Tanperati | -20 jiska +75 degre C |
| Fòs rupture | Min 1.68kg/mm² |
Pwopriyete elektrik:
| Rezistans kondiktè | Maksimòm . 9.38 ohm/100m |
| Dezekilib rezistans | Max. 2% |
| Rezistans izolasyon | 150 ohm/KM |
| Kapasite mityèl | Max. 5600pF/100m |
| Dezekilib kapasite | Max. 330pF/100m |
| Enpedans | 100+/-15 ohm |
| Tès etensèl | 2000V |
| Vitès pwopagasyon | 67% |
Pèfòmans teknik:
| Atténuation | RL | Next | PS Next | |
| (Mhz) | (dB/100M) | (dB) | (dB) | (dB/100m) |
| 1MHz | 2.0 | 20 | 65.3 | 63.5 |
| 4MHz | 4.1 | 23 | 56.3 | 54.2 |
| 8MHz | 5.8 | 24.5 | 52.4 | 50.5 |
| 10MHz | 6.6 | 25 | 51.3 | 49.2 |
| 16MHz | 8.2 | 25 | 49.3 | 47.4 |
| 20MHz | 9.3 | 25 | 48.8 | 46.9 |
| 25MHz | 10.4 | 24 | 45.3 | 43.4 |
| 31.25MHz | 11.7 | 23 | 43.0 | 41.8 |
| 62.5MHz | 17.0 | 21 | 39.2 | 37.2 |
| 100MHz | 22.0 | 20 | 36.3 | 34.4 |
